Cable Manufacturing Equipment

Drum type twisting machine electrical cable manufacturing machine for laying up / armoring

Place of Origin:
Hebei, China (Mainland)
Brand Name:
HONGQI
Model Number:
2500-3150
Usage:
Twisting
Application:
electrical cable manufacturing
color:
red, blue
Type:
2500, 3150
Material:
copper, aluminum, steel, insulated wire
Warranty:
12 Months
Supply Ability:
50 Set/Sets per Year
Packaging Details
Suitable for long distance sea-transportation and well protected against change of climate, moisture and shock.
Port
TIANJIN XINGANG SEA PORT OF CHINA
Lead Time
:
Shipped in 120 days after payment

Product Description
_01_01
Why choose us?

1.34 years experience on cable/wire manufacture equipment

2.Industrial chain advantage:Located in Hebei province in Huabei area,one of the most important heavy industry belt of China,HongQi`s production get:

     –better quality

     –less cost

3.As both manufacture and trader,we can control:

     –the Price
     –the Quality
     –the Delivery time

4.Flexible shipment choice:TIANJIN seaport or SHANGHAI seaport

5.Consummate technical guidance from pre-sale to after-sale

Main Parameter

Model
JPD-2500
JPD-3150
Take-up bobbin
PN2500
PN3150
OD of laid-up cable
120
130
lay up pitch
111-9298
Metal/non-metal taping device
Rotation speed(r/min)
132-478
Pitch(mm)
19-250
Belt Width(mm)
20-60
Rotation speed(r/min)
30
21
Linear speed of production(m/min)
50
9.1-33



Product Photos

 Drum Twister electrical cable manufacturing machine for laying up and armouringDrum Twister electrical cable manufacturing machine for laying up and armouringDrum Twister electrical cable manufacturing machine for laying up and armouringDrum Twister electrical cable manufacturing machine for laying up and armouringDrum Twister electrical cable manufacturing machine for laying up and armouring





Application

This drum twister electric cable manufacturing machine mainly used for twisting large section and length power cable production, making roung or sector core stranding process, also can use for armouring steel wire or copper shield.

rigid stranding machine



Component

Rotating pay-off, wire guiding device, assembling plate, filling stand, steel wire pay-off device, steel wire armouring head, die holder, taping machine, rotary caterpillar, drum stranding take-up, transmission system and electric control system



Our Services

_11



Contact Us

Company Information

Established in 1983,Beijing Xinhan Trading Co,LTD,is a professional manufacture and exporter of cable machine.Our manufacture is located in Hebei province,where is only 200 kilometers away from Beijing.With more than 30 years experience accumulation and technical precipitation,we have independent design and production of complete set of cable equipment capacity.Our main products include Laying-up machine,all kinds of stranding machine,drum twister and extruders.We provide high quality products,good reputaion and perfect after-service for the masses of costomers.



Packaging & Shipping

_14

FAQ

A .About XINGHAN

(1) For new partner,Every salesman of us can tell you what the first step on the equipment ,workshop how to plan,how to save the costs and so on.



(2)Our main products are: cable machine series , corrugated chain armor installed series, box cutter series , fork cutter machine, cage stranding machine, pipe cutter machine, plastic extrusion machine, rubber extruder series and continuous curing unit and so on. Thereinto,JLK12 +18 +21 / 500 box cutter and CL2 +3 / 1600 cable machine has hit a domestic brand , renowned at home.





B.Installation and repair

(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user should provide accommodation and round-trip ticket for our engineer.



(2)Workers are required to assist the installation for big project.



(3)USD 70/day for one person as installation fee.



C. Warranty:

1) 12 months warranty after delivery.



2)Professional after-sales department to provide 24/7 technical support, all complaints should be replied within 24 hours.



3)Over 10 engineers available to service machinery overseas.



4)Free spare parts replacement within warranty period.



 5)Beyond guarantee period, we will charge market price for spare parts.

_15
